This type truck is the famouce brand of CNHTC group in abroad marketing, and make a big effort for local infrastructure construction. Delicate design, excellent technology, which have the advantages of Comfort, safety, reliability geared to international level.
| Dump Truck SINOTRUK HOWO 371HP 12 Wheels LHD 60tons 20-30CBM | ||||
| Model | ZZ3317N3567W | |||
| Drive Type | 8×4 | |||
| Engine |
| |||
| Cabin | HW76 lengthened cab(with one sleeper, air-conditioner and new-style seat) | |||
| Transmission | HW19710(10 forwards & 2 reverses) | |||
| Front Axle | 1×HF9 ( 9 Tons) | |||
| Driving Axle | HC16, 16Tons | |||
| Steering | ZF8118 hydraulic steering with power assistance. | |||
| Clutch | Single-plate dry coil-spring clutch, diameter 430mm, hydraulically operating with air assistance | |||
| Rim/ Tire | 11.00R20,12.00R20,12.00R24 Radial tire | |||
| Wheel base | 1800+3500+1350(mm) | |||
| Overall dimension | 10445×2496×3450(mm) | |||
| Cargo body | 7500×2300×1500(mm),Bottom:8mm, Side:6mm | |||
| The curb weight | 15120(Kg) | |||
| Gross weight | 31000 kg | |||
| Max. speed | 75km/h | |||
| Color | White, red, green, golden and we can also accept customize. | |||
